Knapheide PGNC Gooseneck Body

KNP:PGNC-EQP
Most Flatbeds and Service Bodies Require Your Truck be ¾ Ton or Higher Capacity.
Please Call for Availability
800-346-1704

Description

PGNC Gooseneck Bodies. Versatility with storage solutions to meet every need, Knapheide Gooseneck Bodies are an easy choice. Rugged construction, enhanced styling and secure storage give you a body that can haul it all.
  • Under-the-floor gooseneck hitch system with 2-5/16" ball installed (hitch is rated at 30,000 lb. gross trailer weight with 5,000 lb. tongue weight)
  • Features double-shell, 20-gauge, two-sided A-40 galvanneal steel compartment doors
  • Rugged 12-gauge tread plate floor with 6" structural channel long sills (4" on 8' models)
  • Rub rails installed on both sides of platform for convenient cargo tie downs
  • Aluminum tread plate trim piece on rear hitch plate provides a "no worry" step location
  • Internal stake pockets lining both sides and rear of the platform
  • Durable oven-cured coat, finish painted black
  • Simplified rear skirt styling. Skirted gooseneck styling with integrated front and rear toolboxes. Toolboxes optimized to provide 20% additional storage capacity.
  • Neoprene door seals protect compartments from the weather
  • Continuous stainless steel hinges are pry-proof and corrosion-resistant
  • 12-gauge formed cross sills, spaced on 16" centers
  • Bulkhead and rear skirt include integrated oval LED B/U and S/T/T lights
  • Updated bulkhead punch pattern provides greater visibility and stylized screen window design
  • Hinged access door to cover gooseneck hitch when not in use
  • Automotive quality, rotary-style latches make opening and closing easy. Interior cover protects internal latch from damage.
  • Integrated Class V receiver hitch rated at 12,000 lb. (optional on 8' bodies as most 56" CA chassis include a factory hitch)
  • Safety chain attachment points and 7-way trailer plug included in gooseneck box and at receiver hitch
  • Adjustable security ring strikers provide a weather-tight seal
  • Double-spring over-center door retainer eliminates involuntary door swing
  • All marker, clearance and I.D. lights are LED
  • Integrated driver side fuel fill cup
  • Electrodeposition prime-paint system provides superior corrosion resistance
    • POPULAR OPTIONS:
    • Additional Aluminum Tread Plate Overlay
    • Roughneck Contractor Package
    • 4" Removable Side Boards
    • Above Body & Underbody Toolboxes
    • LED S/T/T Lights
    • 3/16" Tread Plate Floor
